Section
6: Reading buffers 2470 High Voltage SourceMeter Instrument
Reference Manual
6-28 2470-901-01 Rev. A / May 2019
Accessing the data in buffers
Using SCPI commands:
To access a buffer, include the buffer name in the respective command. For example, the following
commands:
Create a buffer named testData to store 100 readings
Set the instrument to make five readings for all measurement requests
Make the readings and store them in the buffer
Return five readings (including the measurement and relative time) from the user-defined buffer
named testData
TRAC:MAKE "testData", 100
SENS:COUN 5
TRAC:TRIG "testData"
TRAC:DATA? 1, 5, "testData", READ, REL
Using TSP commands:
A reading buffer is based on a Lua table. When you use TSP commands, the measurements
themselves are accessed by ordinary array notation. If rb is a reading buffer, the first measurement is
accessed as rb[1], the ninth measurement as rb[9], and so on. The additional information in t
he
table is accessed as additional members of the table.
To access a buffer, include the buffer name in the respective command. For example, the following
commands:
Create a buffer named testData to store 100 readings
Set the instrument to make five readings for all measurement requests
Make the readings and store them in the buffer
Return five readings (including the measurement and relative time) from the user-defined buffer
named testData
-- Create a buffer named testData to store 100 readings.
testData = buffer.make(100)
-- Set the instrument to make 5 readings and store them in the buffer.
trigger.model.load("SimpleLoop", 5, 0, testData)
-- Make the readings
trigger.model.initiate()
waitcomplete()
-- Read the 5 readings and print them including the measurement
-- and relative time for each reading.
printbuffer(1, 5, testData.readings, testData.relativetimestamps)
