1: Introduction 2470 High Voltage SourceMeter Instrument
1-2 2470-901-01 Rev. A / May 2019
Extended warranty
Additional years of warranty coverage are available on many products. These valuable contracts
protect you from unbudgeted service expenses and provide additional years of protection at a fraction
of the price of a repair. Extended warranties are available on new and existing products. Contact your
local Keithley Instruments office, sales partner, or distributor for details.
Contact information
If you have any questions after you review the information in this documentation, please contact your
local Keithley Instruments office, sales partner, or distributor. You can also call the corporate
headquarters of Keithley Instruments (toll-free inside the U.S. and Canada only) at 1-800-935-5595,
or from outside the U.S. at +1-440-248-0400. For worldwide contact numbers, visit the
Keithley
Instruments website (tek.com/keithley).
Organization of manual sections
The information in this manual is organized into the following major categories:
• Installation: Dimensions, installation, power up, instrument access, and remote communications
setup information.
• Instrument description: Descriptions of the hardware and on-screen components of the
i
nstrument.
• Sourcing and measuring: Detail about sourcing and measuring test connections. Also include
des
criptions of features such as relative offset, calculations, limit testing, and configuration lists.
• Source-measure considerations: Best practices and recommended procedures that can
i
ncrease measurement speed, accuracy, and sensitivity.
• Reading buffers: How to use default and user-defined reading buffers to capture data.
• Graphing: How to use the graphing and histogram features to view data on the front panel.
• Triggering: How to start and synchronize source and measure actions on one or more
i
nstruments with a trigger event or a combination of trigger events that you set. Also includes
discussion of the trigger model.
• TSP-Link and TSP-NET: Connecting multiple instruments for high-speed trigger synchronization
bet
ween instruments. Includes how to control the instrument using TSP commands and Test
Script Builder (TSB) software, TSP-Link system expansion, and TSP-Net.
• Maintenance: Instructions for routine maintenance of the instrument, including fuse replacement
and firmware upgrades.
• Introduction to SCPI commands: Describes how to control the instrument using SCPI
commands.
