4: Sourcing and measuring 2470 High Voltage SourceMeter Instrument
4-66 2470-901-01 Rev. A / May 2019
Limit testing and binning
The 2470 can be set up for limit testing and binning. It can perform simple benchtop limit testing using
the front panel or sophisticated limit and binning operations using the trigger model and digital I/O to
control external component-handling devices.
Some typical forms of limit testing include:
• Simple pass-or-fail testing.
• Resistor grading: Inspect multiple limits until the first failure is received.
• Resistor sorting: Inspect multiple limits until the first pass is received.
For binning applications, you use limit testing to determine placement of tested parts. To set up the
instrument to place the part in the correct bin, you do the following steps:
• Determine and record a bin number for later use.
• Output a digital bit pattern to physically place the tested device in a bin.
• If multiple tests are performed on the same part, determine when the part should be binned:
 Bin the part as soon as it fails a test.
 Bin the part after all parameters are measured; bin according to the first failure or
a
combination of failures.
Limit testing allows you to set high and low limit values. When the reading falls outside these limits,
the instrument displays L1FAIL or L2FAIL.
The limit values are stored in volatile memory.
Limits are tested after any selected filter, relative offset, and math functions have been applied to the
measurement.
The 2470 provides two binning trigger model templates to assist with setup, one for grading and one
for sorting. Refer to Predefined trigger models (on page 8-46
).
Limit testing using the front-panel interface
You can do pass or fail limit testing through the front panel. When limit testing and a test fails, the limit
(#1 or #2) that failed is shown on the home screen.
The low value must be less than the high value. If it is not, an automatic limit fail will occur.
