Details

This command sets up a loop that sets a delay, makes a measurement, and then repeats the loop the

number of times you define in the count parameter.

After selecting a trigger model template, you can view the trigger model blocks in a graphical format

by pressing the front-panel MENU key and under Trigger, selecting Configure. You can also add or

delete blocks and change trigger model settings from this screen.

You can use the TRIGger:BLOCk:LIST? command to view the trigger model blocks in a list format.

This command replaces the TRIGger:LOAD:LOOP:SIMPle command, which is deprecated.

Example

*RST

SENS:FUNC "CURR"

SENS:CURR:RANG:AUTO ON

SOUR:FUNC VOLT

SOUR:DEL 0.1

SOUR:VOLT 5

SOUR:VOLT:ILIM 0.01

TRIG:LOAD "SimpleLoop", 10

OUTP ON

INIT

*WAI

TRAC:DATA? 1, 10, "defbuffer1", SOUR, READ, REL

Reset the instrument and set it to measure

current with automatic range setting.

Source 5 V with a source delay of 0.1 s.

Set a current limit of 0.01 A.

Set a simple trigger loop with a count of 10.

Turn the output on.

Start the trigger model.

Postpone execution of subsequent

commands until all previous commands are

finished.

Read data and store the source, reading,

and relative time.

Also see

:TRIGger:BLOCk:LIST? (on page 12-164)

:TRIGger:LOAD "SortBinning"

This command loads a predefined trigger model configuration that sets up a sorting operation.

Type Affected by Where saved Default value

Command only Not applicable Not applicable Not applicable

Usage
