Tektronix Keithley SourceMeter 2470 Reference Manual

Section
12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-190 2470-901-01 Rev. A / May 2019
:TRIGger:LOAD "SortBinning", <components>, <startInLine>, <startDelay>, <endDelay>,
<limit1High>, <limit1Low>, <limit1Pattern>, <allPattern>, <limit2High>,
<limit2Low>, <limit2Pattern>, <limit3High>, <limit3Low>
:TRIGger:LOAD "SortBinning", <components>, <startInLine>, <startDelay>, <endDelay>,
<limit1High>, <limit1Low>, <limit1Pattern>, <allPattern>, <limit2High>,
<limit2Low>, <limit2Pattern>, <limit3High>, <limit3Low>, <limit3Pattern>
:TRIGger:LOAD "SortBinning", <components>, <startInLine>, <startDelay>, <endDelay>,
<limit1High>, <limit1Low>, <limit1Pattern>, <allPattern>, <limit2High>,
<limit2Low>, <limit2Pattern>, <limit3High>, <limit3Low>, <limit3Pattern>,
<limit4High>
:TRIGger:LOAD "SortBinning", <components>, <startInLine>, <startDelay>, <endDelay>,
<limit1High>, <limit1Low>, <limit1Pattern>, <allPattern>, <limit2High>,
<limit2Low>, <limit2Pattern>, <limit3High>, <limit3Low>, <limit3Pattern>,
<limit4High>, <limit4Low>
:TRIGger:LOAD "SortBinning", <components>, <startInLine>, <startDelay>, <endDelay>,
<limit1High>, <limit1Low>, <limit1Pattern>, <allPattern>, <limit2High>,
<limit2Low>, <limit2Pattern>, <limit3High>, <limit3Low>, <limit3Pattern>,
<limit4High>, <limit4Low>, <limit4Pattern>
:TRIGger:LOAD "SortBinning", <components>, <startInLine>, <startDelay>, <endDelay>,
<limit1High>, <limit1Low>, <limit1Pattern>, <allPattern>, <limit2High>,
<limit2Low>, <limit2Pattern>, <limit3High>, <limit3Low>, <limit3Pattern>,
<limit4High>, <limit4Low>, <limit4Pattern>, "<bufferName>"
<components>
The number of components to measure
<startInLine>
The input line that starts the test; 5 for digital line 5, 6 for digital line 6; default is 5
<startDelay>
The delay time before each measurement (167 ns to 10 ks); default is 0 for no delay
<endDelay>
The delay time after the measurement (167 ns to 10 ks); default is 0 for no delay
<limitxHigh>
x
is limit 1, 2, 3, or 4; the upper limit that the measurement is compared against
<limitxLow>
x is 1, 2, 3, or 4; the lower limit that the measurement is compared against
<limit1Pattern>
The bit pattern that is sent when the measurement passes limit 1; range 1 to 15;
default is 1
<limit2Pattern>
The bit pattern that is sent when the measurement passes limit 2; range 1 to 15;
default is 2
<limit3Pattern>
The bit pattern that is sent when the measurement passes limit 3; range 1 to 15;
default is 4
<limit4Pattern>
The bit pattern that is sent when the measurement passes limit 4; range 1 to 15;
default is 8
<allPattern>
The bit pattern that is sent when all limits have failed; 1 to 15; default is 15
<bufferName>
A string that indicates the reading buffer; the default buffers (
defbuffer1
or
defbuffer2) or the name of a user-defined buffer; if no buffer is specified,
defbuffer1
is used
Details
This trigger model template allows you to sort components and place them into up to four bins, based
on the comparison to limits.
To set a limit as unused, set the high value for the limit to be less than the low limit.
All limit patterns and the all fail pattern are sent on digital I/O lines 1 to 4, where 1 is the least
significant bit.
