Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument Referen
ce Manual
14-214 2470-901-01 Rev. A / May 2019
If any events are detected before the trigger LAN connection is sent, the event is ignored and the
action overrun is set.
Trigger events
Event description Event constant
Trigger event blender N (1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
A command interface trigger:
 Any remote interface: *TRG
 GPIB only: GET bus command
 USB only: A USBTMC TRIGGER message
 VXI-11: VXI-11 command
device_trigger
trigger.EVENT_COMMAND
Digital input line edge (either rising, falling, or either based on
the configuration of the line) detected on digital input line N
(1 to 6)
trigger.EVENT_DIGION
Front-panel TRIGGER key press
trigger.EVENT_DISPLAY
Appropriate LXI trigger packet is received on LAN trigger
object N (1 to 8)
trigger.EVENT_LANN
No trigger event
trigger.EVENT_NONE
Notify trigger block N (1 to 8) generates a trigger event when
the trigger model executes it
trigger.EVENT_NOTIFYN
Source limit condition occurs
trigger.EVENT_SOURCE_LIMIT
Trigger timer N (1 to 4) expired
trigger.EVENT_TIMERN
Line edge detected on TSP-Link synchronization line N
(1 to 3)
trigger.EVENT_TSPLINKN
Example
trigger.lanout[5].stimulus = trigger.EVENT_TIMER1
Use the timer 1 trigger event as the source for LAN trigger 5 stimulus.
Also see
trigger.lanout[N].connect() (on page 14-209)
trigger.lanout[N].ipaddress (on page 14-211)
trigger.model.abort()
This function stops all trigger model commands on the instrument.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.model.abort()
Details
When this command is received, the instrument stops the trigger model.
