Section
12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-174 2470-901-01 Rev. A / May 2019
:TRIGger:DIGital<n>:OUT:PULSewidth
This command describes the length of time that the trigger line is asserted for output triggers.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
10e-6 (10 µs)
Usage
:TRIGger:DIGital<n>:OUT:PULSewidth <width>
:TRIGger:DIGital<n>:OUT:PULSewidth?
<n>
Digital I/O trigger line (1 to 6)
<width>
Pulse length (0 to 100 ks)
Details
Setting the pulse width to zero (0) seconds asserts the trigger indefinitely.
Example
DIG:LINE1:MODE TRIG, OUT
TRIG:DIG1:OUT:PULS 2
Set digital line 1 to trigger out.
Set the pulse to 2 s.
Also see
:DIGital:LINE<n>:MODE (on page 12-24)
:DIGital:WRITe <n> (on page 12-27)
Digital I/O port configuration (on page 8-13)
:TRIGger:DIGital<n>:OUT:STIMulus
This command selects the event that causes a trigger to be asserted on the digital output line.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Save settings NONE
Usage
:TRIGger:DIGital<n>:OUT:STIMulus <event>
:TRIGger:DIGital<n>:OUT:STIMulus?
<n>
Digital I/O trigger line (1 to 6)
<event>
The event to use as a stimulus; see Details
