High Voltage SourceMeter Instrument Reference Manual Section 14:
2470-901-01 Rev. A / May 2019 14-183
status.operation.getmap()
This function requests the mapped set event and mapped clear event status for a bit in the Operation Event
Registers.
Type TSP-Link accessible
Affected by Where saved Default value
Usage
setEvent, clearEvent = status.operation.getmap(bitNumber)
The event mapped to set this bit; 0 if no mapping
The event mapped to clear this bit; 0 if no mapping
Details
When you query the mapping for a specific bit, the instrument returns the events that were mapped to
set and clear that bit. Zero (0) indicates that the bits have not been set.
Example
print(status.operation.getmap(0))
Query bit 0 of the Operation Event Register.
Example output:
Also see
Operation Event Register (on page B-7)
Programmable status register sets (on page B-4)
status.operation.setmap() (on page 14-183)
status.operation.setmap()
This function allows you to map events to bits in the Operation Event Register.
Type TSP-Link accessible
Affected by Where saved Default value
Usage
status.operation.setmap(bitNumber, setEvent)
status.operation.setmap(bitNumber, setEvent, clearEvent)
The bit number that is mapped to an event (0 to 14)
The number of the event that sets the bits in the condition and event registers; 0 if no
mapping
The number of the event that clears the bit in the condition register; 0 if no mapping
