High Voltage SourceMeter Instrument Reference Manual Section 12:
2470-901-01 Rev. A / May 2019 12-155
Example
CALC2:LIM1:LOW -5.17
CALC2:LIM1:UPP -4.23
TRIG:BLOC:BRAN:LIM:DYN 9, IN, 1, 12, 7
Set the limits on with a low limit of -5.17 and
a high limit of -4.23. Set trigger block 9 to test
if the limit is inside those limits based on the
measurement reading at block 7. If the
measurement is within the limits, go to block
Also see
Dynamic Limit block (on page 8-40)
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] (on page 12-20)
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page 12-23)
:TRIGger:BLOCk:BRANch:ONCE
This command causes the trigger model to branch to a specified building block the first time it is encountered in
the trigger model.
Type Affected by Where saved Default value
Command only Recall settings
Instrument reset
Save settings Not applicable
Usage
:TRIGger:BLOCk:BRANch:ONCE <blockNumber>, <branchToBlock>
The sequence of the block in the trigger model
The block number of the trigger model block to execute when the trigger model first
encounters this block
Details
The branch-once building block branches to a specified block the first time trigger model execution
encounters the branch-once block. If it is encountered again, the trigger model ignores the block and
continues in the normal sequence.
The once block is reset when trigger model execution reaches the idle state. Therefore, the
branch-once block always executes the first time the trigger model execution encounters this block.
Example
:TRIG:BLOC:BRAN:ONCE 2, 4
The first time the trigger model reaches block 2, the trigger model goes to block 4 instead of proceeding to the
default sequence of block 3.
Also see
Once block (on page 8-42)
:TRIGger:BLOCk:BRANch:ONCE:EXCLuded (on page 12-156)
