Tektronix Keithley SourceMeter 2470 Reference Manual

2470
High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-195
Example
TRIG:TIM1:STAR:SEC 60
TRIG:TIM1:START:FRAC 0.5
TRIG:TIM1:STAT ON
Set the timer for 60.5 s.
Enable the trigger timer for timer 1.
Also see
:TRIGger:TIMer<n>:STARt:SEConds (on page 12-196)
:TRIGger:TIMer<n>:STATe (on page 12-198)
:TRIGger:TIMer<n>:STARt:GENerate
This command specifies when timer events are generated.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
0 (OFF)
Usage
:TRIGger:TIMer<n>:STARt:GENerate <state>
:TRIGger:TIMer<n>:STARt:GENerate?
<n>
Trigger timer number (1 to 4)
<state>
Generate a timer event when the timer delay elapses: OFF or 0
Generate a timer event when the timer starts and when the delay elapses:
ON
or
1
Details
When this is set to on, a trigger event is generated immediately when the timer is triggered.
When it is set to off, a trigger event is generated when the timer elapses. This generates the event
TIMERN.
Example
TRIG:TIM3:STAR:GEN ON
Set trigger timer 3 to generate an event when the timer starts
and when the timer delay elapses.
Also see
None
:TRIGger:TIMer<n>:STARt:OVERrun?
This command indicates if an event was ignored because of the event detector state.
Type Affected by Where saved Default value
Query only
Not applicable
Not applicable
Not applicable
Usage
:TRIGger:TIMer<n>:STARt:OVERrun?
<n>
Trigger timer number (1 to 4)
