High Voltage SourceMeter Instrument Reference Manual Section 14:
TSP command reference
2470-901-01 Rev. A / May 2019 14-133
smu.measure.limit[Y].high.value
This attribute specifies the upper limit for a limit test.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Function change
Configuration script
Measure configuration list
1
Usage
highLimit = smu.measure.limit[Y].high.value
smu.measure.limit[Y].high.value = highLimit
highLimit
The value of the high limit (
−
9.99999e+11 to +9.99999e+11)
Y
Limit number: 1 or 2
Details
This command sets the high limit for the limit Y test for the selected measurement function. When limit
Y testing is enabled, the instrument generates a fail indication when the measurement value is more
than this value.
Example
See the example in smu.measure.limit[Y].fail (on page 14-131).
Also see
smu.measure.limit[Y].enable (on page 14-130)
smu.measure.limit[Y].low.value
This attribute specifies the lower limit for limit tests.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes Restore configuration
Instrument reset
Power cycle
Measure configuration list
Function change
Configuration script
Measure configuration list
−1
Usage
lowLimit = smu.measure.limit[Y].low.value
smu.measure.limit[Y].low.value = lowLimit
lowLimit
The low limit value of limit
Y
(-9.99999E+11 to 9.99999E+11)
Y
Limit number: 1 or 2
Details
This command sets the lower limit for the limit Y test for the selected measure function. When limit Y
testing is enabled, this causes a fail indication to occur when the measurement value is less than this
value.
