Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-250 2470-901-01 Rev. A / May 2019
Trigger events
Event description Event constant
Trigger event blender N (1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
Appropriate LXI trigger packet is received on LAN trigger
object N (1 to 8)
trigger.EVENT_LANN
No trigger event
trigger.EVENT_NONE
Notify trigger block N (1 to 8) generates a trigger event when
the trigger model executes it
trigger.EVENT_NOTIFYN
Source limit condition occurs
trigger.EVENT_SOURCE_LIMIT
Trigger timer N (1 to 4) expired
trigger.EVENT_TIMERN
Line edge detected on TSP-Link synchronization line N
(1 to 3)
trigger.EVENT_TSPLINKN
Example
trigger.model.setblock(9, trigger.BLOCK_WAIT, trigger.EVENT_DISPLAY)
Set trigger model block 9 to wait for a user to press the TRIGGER key on the front panel before continuing.
Also see
Wait block (on page 8-29)
trigger.model.state()
This function returns the present state of the trigger model.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
status, status, n = trigger.model.state()
status
The status of the trigger model:
 trigger.STATE_ABORTED
 trigger.STATE_ABORTING
 trigger.STATE_BUILDING
 trigger.STATE_EMPTY
 trigger.STATE_FAILED
 trigger.STATE_IDLE
 trigger.STATE_RUNNING

trigger.STATE_WAITING
n
The last trigger model block that was executed
