12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-40 2470-901-01 Rev. A / May 2019
:OUTPut[1][:STATe]
This command enables or disables the source output.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Source configuration list
Save settings
Source configuration list
0 (OFF)
Usage
:OUTPut[1][:STATe] <state>
:OUTPut[1][:STATe]?
<state>
Turn source off: 0 or OFF
Turn source on: 1 or ON
Details
When the output is switched on, the instrument sources either voltage or current, as set by
:SOURce[1]:FUNCtion[:MODE].
Example
:OUTP ON
Switch the source output of the instrument to
on.
Also see
:SOURce[1]:FUNCtion[:MODE] (on page 12-80)
ROUTe subsystem
The ROUTe subsystem selects which set of input and output terminals to enable (front panel or rear
panel).
:ROUTe:TERMinals
This command describes which set of input and output terminals the instrument is using.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
FRON
Usage
:ROUTe:TERMinals <location>
:ROUTe:TERMinals?
<location>
Use the front-panel input and output terminals: FRONt
Use the rear-panel input and output terminals: REAR
