Tektronix Keithley SourceMeter 2470

2470
High Voltage SourceMeter Instrument Reference Manual Section 14:
TSP command reference
2470-901-01 Rev. A / May 2019 14-203
trigger.digout[N].pulsewidth
This attribute describes the length of time that the trigger line is asserted for output triggers.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Digital I/O trigger N reset
Configuration script
10e-6 (10
µ
s)
Usage
width = trigger.digout[N].pulsewidth
trigger.digout[N].pulsewidth = width
width
The pulse width (0 to 100 ks)
N
Digital I/O trigger line (1 to 6)
Details
Setting the pulse width to zero (0) seconds asserts the trigger indefinitely. To release the trigger line,
use trigger.digout[N].release().
Example
digio.line[4].mode = digio.MODE_TRIGGER_OUT
trigger.digout[4].pulsewidth = 20e-6
Sets the pulse width for trigger line 4 to
20
µ
s.
Also see
digio.line[N].mode (on page 14-52)
digio.line[N].reset() (on page 14-53)
Digital I/O port configuration (on page 8-13)
trigger.digout[N].assert() (on page 14-201)
trigger.digout[N].release() (on page 14-204)
