Tektronix Keithley SourceMeter 2470 Reference Manual

2470
High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-167
Example
TRIG:BLOC:NOP 5
Set block number 5 to be a no operation block.
Also see
None
:TRIGger:BLOCk:NOTify
This command defines a trigger model block that generates a trigger event and immediately continues to the next
block.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:TRIGger:BLOCk:NOTify <blockNumber>, <notifyID>
<blockNumber>
The sequence of the block in the trigger model
<notifyID>
The identification number of the notification; 1 to 8
Details
When trigger model execution reaches a notify block, the instrument generates a trigger event and
immediately continues to the next block.
Other commands can reference the event that the notify block generates. This assigns a stimulus
somewhere else in the system. For example, you can use the notify event as the stimulus of a
hardware trigger line, such as a digital I/O line.
When you call this event, you use the format NOTIFY followed by the notify identification number. For
example, if you assign <notifyID> as 4, you would refer to it as NOTIFY4 in the command that
references it.
Example
:TRIG:BLOC:NOT 5, 2
:TRIG:BLOC:BRAN:EVEN 6, NOTIFY2, 2
Define trigger model block 5 to be the notify
2 event. Assign the notify 2 event to be the
trigger for stimulus for the branch event for
block 6.
Also see
Notify block (on page 8-32)
