Tektronix Keithley SourceMeter 2470

Section
4: Sourcing and measuring 2470 High Voltage SourceMeter Instrument
Reference Manual
4-52 2470-901-01 Rev. A / May 2019
Setting mx+b math operations
From the front panel:
1. Press the FUNCTION key and select the measure function.
2. Press the MENU key.
3. Under Measure, select Calculations.
4. For Math, select On.
5. Select Config.
6. For Math Format, select mx+b.
7. For m(Scalar), set the m value.
8. For b(Offset), set the b value.
9. Select OK.
10. Press the HOME key to view the measurement with the mx+b math format applied.
Over a remote interface:
• SCPI commands: Refer to :CALCulate[1]:<function>:MATH:FORMat (on page
12-10), :CALCulate[1]:<function>:MATH:MMFactor (on page 12-13),
and :CALCulate[1]:<function>:MATH:MBFactor (on page 12-11).
• TSP commands: Refer to smu.measure.math.format (on page 14-135),
smu.measure.math.mxb.bfactor (on page 14-136), and smu.measure.math.mxb.mfactor (on page
14-137).
Setting reciprocal math operations
From the front panel:
1. Press the FUNCTION key and select the measure function.
2. Press the MENU key.
3. Under Measure, select Calculations.
4. For Math, select On.
5. Select Config.
6. For Math Format, select Reciprocal
7. Select OK.
8. Press the HOME key to view the measurement with the reciprocal math format applied.
Over a remote interface:
• SCPI commands: Refer to :CALCulate[1]:<function>:MATH:FORMat (on page 12-10).
• TSP commands: Refer to smu.measure.math.format (on page 14-135) and
smu.measure.math.enable (on page 14-134).
