High Voltage SourceMeter Instrument Reference Manual Section 12:
2470-901-01 Rev. A / May 2019 12-77
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude]
This command immediately selects a fixed amplitude for the selected source function.
Type Affected by Where saved Default value
Instrument reset
Power cycle
Source configuration list
Source configuration list
Usage
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude] <value>
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude] <DEF|MIN|MAX>
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude]?
:SOURce[1]:<function>[:LEVel][:IMMediate][:AMPLitude]? <DEF|MIN|MAX>
The source function to which this setting applies:
 Current: CURRent
 Voltage:
 Current: −1.05 A to 1.05 A
−
The DEFault, MINimum, or MAXimum value
Details
This command sets the output level of the voltage or current source. If the output is on, the new level
is sourced immediately.
The sign of the source level dictates the polarity of the source. Positive values generate positive
voltage or current from the high terminal of the source relative to the low terminal. Negative values
generate negative voltage or current from the high terminal of the source relative to the low terminal.
If a manual source range is selected, the level cannot exceed the specified range. For example, if the
voltage source is on the 2 V range, you cannot set the voltage source level to 3 V. When autorange is
selected, the amplitude can be set to any level supported by the instrument.
Example
SOUR:FUNC VOLT
SOUR:VOLT 1
Set the instrument to source voltage and set
it to source 1 V.
Also see
:SOURce[1]:<function>:RANGe (on page 12-82)
:SOURce[1]:<function>:RANGe:AUTO (on page 12-83)
