High Voltage SourceMeter Instrument Reference Manual Section 13:
Introduction to TSP commands
2470-901-01 Rev. A / May 2019 13-33
Figure 141: Example of the Test Script Builder workspace
Item Description
Script editor; right-click to run the script that is displayed
Help; includes detailed information on using Test Script Builder
Project navigator
The project navigator consists of project folders and the script files (.tsp) created for each project.
Each project folder can have one or more script files.
To view the script files in a project folder, click the plus (+) symbol next to the project folder. To hide
the folder contents, click the minus (−) symbol next to the project folder.
You can download a TSP project to the instrument and run it, or you can run it from the TSB
interface.
