Tektronix Keithley SourceMeter 2470

2470
High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-173
Example
TRIG:DIG1:IN:OVER?
Returns 0 if no overruns have occurred or 1 if one or more
overruns have occurred for I/O line 1.
Also see
Digital I/O port configuration (on page 8-13)
:DIGital:LINE<n>:MODE (on page 12-24)
:TRIGger:DIGital<n>:OUT:LOGic
This command sets the output logic of the trigger event generator to positive or negative for the specified line.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
NEG
Usage
:TRIGger:DIGital<n>:OUT:LOGic <logicType>
:TRIGger:DIGital<n>:OUT:LOGic?
<n>
Digital I/O trigger line (1 to 6)
<logicType>
The output logic of the trigger generator:
 Assert a TTL-high pulse for output: POSitive
 Assert a TTL-low pulse for output:
NEGative
Details
This command sets the trigger event generator to assert a TTL pulse for output logic. Positive is a
high pulse; negative is a low pulse.
Example
:DIG:LINE4:MODE TRIG, OUT
:TRIG:DIG4:OUT:LOG NEG
Sets line 4 mode to be a trigger output and sets the output logic
of the trigger event generator to negative (asserts a low pulse).
Also see
:DIGital:LINE<n>:MODE (on page 12-24)
Digital I/O port configuration (on page 8-13)
