High Voltage SourceMeter Instrument Reference Manual Section 14:
2470-901-01 Rev. A / May 2019 14-271
Also see
Initializing the TSP-Link system (on page 9-4)
localnode.showevents (on page 14-94)
tsplink.node (on page 14-274)
tsplink.state (on page 14-275)
tsplink.line[N].mode
This attribute defines the trigger operation of a TSP-Link line.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes Restore configuration
Instrument reset
Power cycle
TSP-Link line N reset
Configuration script tsplink.MODE_DIGITAL_OPEN_DRAIN
Usage
mode = tsplink.line[N].mode
tsplink.line[N].mode = mode
The trigger mode; see Details
The trigger line (1 to 3)
Details
This command defines whether or not the line is used as a digital or trigger control line and if it is an
input or output.
The line mode can be set to the following options:
• TSP-Link digital open drain line: tsplink.MODE_DIGITAL_OPEN_DRAIN
• TSP-Link trigger open drain line: tsplink.MODE_TRIGGER_OPEN_DRAIN
• TSP-Link trigger synchronous master: tsplink.MODE_SYNCHRONOUS_MASTER
• TSP-Link trigger synchronous acceptor: tsplink.MODE_SYNCHRONOUS_ACCEPTOR
Example
tsplink.line[3].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN
Sets the trigger mode for synchronization line 3 as a trigger open drain line.
Also see
trigger.tsplinkin[N].edge (on page 14-262)
trigger.tsplinkout[N].logic (on page 14-265)
