High Voltage SourceMeter Instrument Reference Manual Section 14:
2470-901-01 Rev. A / May 2019 14-213
Details
The LAN trigger listens for trigger messages on all the supported protocols. However, it uses the
designated protocol for sending outgoing messages.
After you change this setting, you must re-connect the LAN trigger event generator before you can
send outgoing event messages.
When multicast is selected, the trigger IP address is ignored and event messages are sent to the
multicast address 224.0.23.159.
Example
print(trigger.lanout[1].protocol)
Get LAN protocol that is being used for sending trigger
messages for LAN event 1.
Also see
trigger.lanout[N].connect() (on page 14-209)
trigger.lanout[N].ipaddress (on page 14-211)
trigger.lanout[N].stimulus
This attribute specifies events that cause this trigger to assert.
Type TSP-Link accessible Affected by Where saved Default value
Instrument reset
Usage
LANevent = trigger.lanout[N].stimulus
trigger.lanout[N].stimulus = LANevent
The LAN event that causes this trigger to assert; see Details for values
A number specifying the trigger packet over the LAN for which to set or query the
trigger source (1 to 8)
Details
This attribute specifies which event causes a LAN trigger packet to be sent for this trigger. Set the
event to one of the existing trigger events, which are shown in the following table.
Setting this attribute to none disables automatic trigger generation.
