12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-16 2470-901-01 Rev. A / May 2019
Example
:CALC:VOLT:MATH:FORM MXB
:CALC:VOLT:MATH:MMF 0.80
:CALC:VOLT:MATH:MBF 50
:CALC:VOLT:MATH:STAT ON
Set the math function for voltage measurements to mx+b.
Set the scale factor for voltage measurements to 0.80.
Set the offset factor to 50.
Enable the math function.
Also see
:CALCulate[1]:<function>:MATH:FORMat (on page 12-10)
Calculations that you can apply to measurements (on page 4-49)
:CALCulate2:<function>:LIMit<Y>:AUDible
This command determines if the instrument beeper sounds when a limit test passes or fails.
Type Affected by Where saved Default value
Command and query Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
NONE
Usage
:CALCulate2:<function>:LIMit<Y>:AUDible <state>
:CALCulate2:<function>:LIMit<Y>:AUDible?
<function>
The measure function:
 Current: CURRent[:DC]
 Resistance: RESistance
 Voltage:
VOLTage[:DC]
<Y>
Limit number: 1 or 2
<state>
When the beeper sounds:
 Never: NONE
 On test failure: FAIL
 On test pass:
PASS
Details
The tone and length of beeper cannot be adjusted.
If you send this command without the <function> parameter, it will set the limit for all measure
f
unctions.
