Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-130 2470-901-01 Rev. A / May 2019
Details
Use this command to clear the test results of limit Y when the limit auto clear option is turned off. Both
the high and low test results are cleared.
To avoid the need to manually clear the test results for a limit, turn the auto clear option on.
Example
smu.measure.func = smu.FUNC_DC_CURRENT
smu.measure.limit[2].clear()
Clears the test result for the high and low limit 2 for
current measurements.
Also see
smu.measure.limit[Y].autoclear (on page 14-129)
smu.measure.limit[Y].enable
This attribute enables or disables a limit test on the measurement from the selected measure function.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Function change
Configuration script
Measure configuration list
smu.OFF
Usage
state = smu.measure.limit[Y].enable
smu.measure.limit[Y].enable = state
state
Disable the test: smu.OFF
Enable the test:
smu.ON
Y
Limit number: 1 or 2
Details
This command enables or disables a limit test for the selected measurement function. When this
attribute is enabled, the limit Y testing occurs on each measurement made by the instrument. Limit Y
testing compares the measurements to the high-limit and low-limit values. If a measurement falls
outside these limits, the test fails.
Example
smu.measure.func = smu.FUNC_DC_VOLTAGE
smu.measure.limit[1].enable = smu.ON
Enable testing for limit 1 when measuring
voltage.
Also see
smu.measure.limit[Y].autoclear (on page 14-129)
smu.measure.limit[Y].clear() (on page 14-129)
smu.measure.limit[Y].fail (on page 14-131)
smu.measure.limit[Y].high.value (on page 14-133)
smu.measure.limit[Y].low.value (on page 14-133)
