14: TSP command reference 2470 High Voltage SourceMeter Instrument Referen

ce Manual

14-150 2470-901-01 Rev. A / May 2019

smu.reset()

This function turns off the output and resets the commands that begin with smu. to their default settings.

Type TSP-Link accessible

Affected by Where saved Default value

Function

Yes

Usage

smu.reset()

Details

This function turns off the output and resets the commands that begin with smu. to their default

settings.

Example

smu.reset()

Turns off the output and resets the SMU

commands to their default settings.

Also see

reset() (on page 14-104)
