Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-204 2470-901-01 Rev. A / May 2019
trigger.digout[N].release()
This function releases an indefinite length or latched trigger.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.digout[N].release()
N
Digital I/O trigger line (1 to 6)
Details
Releases a trigger that was asserted with an indefinite pulsewidth time. It also releases a trigger that
was latched in response to receiving a synchronous mode trigger. Only the specified trigger line is
affected.
Example
digio.line[4].mode = digio.MODE_TRIGGER_OUT
trigger.digout[4].release()
Releases digital I/O trigger line 4.
Also see
digio.line[N].mode (on page 14-52)
Digital I/O port configuration (on page 8-13)
trigger.digout[N].assert() (on page 14-201)
trigger.digout[N].pulsewidth (on page 14-203)
trigger.digout[N].stimulus
This attribute selects the event that causes a trigger to be asserted on the digital output line.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Digital I/O trigger N reset
Configuration script
trigger.EVENT_NONE
Usage
event = trigger.digout[N].stimulus
trigger.digout[N].stimulus = event
event
The event to use as a stimulus; see Details
N
Digital I/O trigger line (1 to 6)
