Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-194 2470-901-01 Rev. A / May 2019
Example
trigger.blender[1].orenable = true
trigger.blender[1].stimulus[1] = trigger.EVENT_DIGIO3
trigger.blender[1].stimulus[2] = trigger.EVENT_DIGIO5
Generate a trigger blender 1 event when a digital I/O trigger happens on line 3 or 5.
Also see
trigger.blender[N].reset() (on page 14-194)
trigger.blender[N].overrun
This attribute indicates whether or not an event was ignored because of the event detector state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R)
Yes
Instrument reset
Trigger blender N clear
Trigger blender N reset
Not applicable
Not applicable
Usage
overrun = trigger.blender[N].overrun
overrun
Trigger blender overrun state (true or false)
N
The blender number (up to two)
Details
Indicates if an event was ignored because the event detector was already in the detected state when
the event occurred. This is an indication of the state of the event detector that is built into the event
blender itself.
This command does not indicate if an overrun occurred in any other part of the trigger model or in any
other trigger object that is monitoring the event. It also is not an indication of an action overrun.
Example
print(trigger.blender[1].overrun)
If an event was ignored, the output is true.
If an event was not ignored, the output is
false
.
Also see
trigger.blender[N].reset() (on page 14-194)
trigger.blender[N].reset()
This function resets some of the trigger blender settings to their factory defaults.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.blender[N].reset()
N
The trigger event blender (up to two)
