High Voltage SourceMeter Instrument Reference Manual Section 8:
2470-901-01 Rev. A / May 2019 8-5
You can set the LAN trigger edge detection method in incoming LXI trigger packets. The edge that is
selected also determines the hardware value in outgoing LXI trigger packets. The following table lists
the LAN trigger edges.
Trigger mode Input detected Output generated
LAN trigger objects generate LXI trigger events, which are LAN0 to LAN7 (zero based). To specify the
LAN trigger event in a command, use LANN, where N is 1 to 8. LAN1 corresponds to LXI trigger event
LAN0 and LAN8 corresponds to LXI trigger event LAN7. To specify the LAN trigger event in
a
c
ommand, see Trigger events (on page 8-53
).
Generate LXI trigger packets
You can configure the 2470 to output an LXI trigger packet to other LXI instruments.
To generate LXI trigger packets:
1. Call the SCPI :TRIGger:LAN<n>:OUT:CONNect:STATe command or TSP
trigger.lanout[N].connect() function.
2. Select the event that triggers the outgoing LXI trigger packet by assigning the specific event t
o
the LAN stimulus input using the SCPI :TRIGger:LAN<n>:OUT:STIMulus command or TSP
trigger.lanout[N].stimulus attribute.
Make sure to use the same LXI domain on both the 2470 instrument and the other instrument. If the
2470 has a different LXI domain from the instrument at the other end of the trigger connection, the
LXI trigger packets are ignored by both instruments.
Trigger timers
You can use trigger timers to add delays, change the source value, and start measurements at timed
intervals. The 2470 has four independent timers that you can use.
Trigger timers are only available over a remote interface. You can set the count, delay, and when the
trigger occurs for the trigger timers. You need to enable the trigger timers before using the
SCPI :TRIGger:TIMer<n>:STATe or the TSP trigger.timer[N].enable command.
