2470
High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-163
:TRIGger:BLOCk:DIGital:IO
This command defines a trigger model block that sets the lines on the digital I/O port high or low.
Type Affected by Where saved Default value
Command only Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRIGger:BLOCk:DIGital:IO <blockNumber>, <bitPattern>
:TRIGger:BLOCk:DIGital:IO <blockNumber>, <bitPattern>, <bitMask>
<blockNumber>
The sequence of the block in the trigger model
<bitPattern>
Sets the value that specifies the output line bit pattern (0 to 63)
<bitMask>
Specifies the bit mask; if omitted, all lines are driven (0 to 63)
Details
To set the lines on the digital I/O port high or low, you can send a bit pattern that is specified as an
integer value. The least significant bit maps to digital I/O line 1 and the most significant bit maps to
digital I/O line 6.
The bit mask defines the bits in the pattern that are driven high or low. A binary 1 in the bit mask
indicates that the corresponding I/O line should be driven according to the bit pattern. To drive all
lines, specify all ones (63) or omit this parameter. If the bit for a line in the bit pattern is set to 1, the
line is driven high. If the bit is set to 0 in the bit pattern, the line is driven low.
For this block to work as expected, make sure you configure the trigger type and line state of the
digital line for use with the trigger model (use the digital line mode command).
Example
:DIGital:LINE3:MODE DIG,OUT
:DIGital:LINE4:MODE DIG,OUT
:DIGital:LINE5:MODE DIG,OUT
:DIGital:LINE6:MODE DIG,OUT
:TRIG:BLOC:DIG:IO 4, 20, 60
The first four lines of code configures digital I./O lines 3 through
6 as digital outputs.
Trigger block 4 is then configured with a bit pattern of 20
(digital I/O lines 3 and 5 high). The optional bit mask is
specified as 60 (lines 3 through 6), so both lines 3 and 5 are
driven high.
Also see
:DIGital:LINE<n>:MODE (on page 12-24)
Digital I/O bit weighting (on page 8-24)
Digital I/O port configuration (on page 8-13)
