High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-79
Example
:SOUR:CURR:VLIM 15
Set the voltage limit to 15 V.
Also see
:SOURce[1]:<function>:PROTection[:LEVel] (on page 12-80)
:SOURce[1]:<function>:<x>LIMit[:LEVel]:TRIPped? (on page 12-79)
:SOURce[1]:<function>:<x>LIMit[:LEVel]:TRIPped?
This command indicates if the source exceeded the limits that were set for the selected measurements.
Type Affected by Where saved Default value
Query only
Not applicable
Not applicable
Not applicable
Usage
:SOURce[1]:CURRent:VLIMit[:LEVel]:TRIPped?
:SOURce[1]:VOLTage:ILIMit[:LEVel]:TRIPped?
Details
You can use this command to check the limit state of the source.
If the limits were exceeded, the instrument clamps the source to keep the source within the set limits.
If the source did not exceed the set limits, the return is 0. If the source did exceed the set limits, t
he
return is 1.
Example 1
SOUR:CURR:VLIM:TRIP?
Returns a value that indicates whether or
not the source exceeded the current limits.
Example 2
SOUR:VOLT:ILIM:TRIP?
Return value indicates whether or not the
source has exceeded the voltage limits.
Also see
:SOURce[1]:<function>:<x>LIMit[:LEVel] (on page 12-78)
