Tektronix Keithley SourceMeter 2470 Reference Manual

Section
12: SCPI command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
12-144 2470-901-01 Rev. A / May 2019
:TRIGger:BLENder<n>:MODE
This command selects whether the blender performs OR operations or AND operations.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Trigger blender clear
Save settings
AND
Usage
:TRIGger:BLENder<n>:MODE <operation>
:TRIGger:BLENder<n>:MODE?
<n>
The blender number (up to two)
<operation>
The type of operation:
 OR

AND
Details
This command selects whether the blender waits for any one event (OR) or waits for all selected
ev
ents (AND) before signaling an output event.
Example 1
:DIG:LINE3:MODE TRIG, IN
:DIG:LINE5:MODE TRIG, IN
:TRIG:BLEN1:MODE OR
:TRIG:BLEN1:STIM1 DIG3
:TRIG:BLEN1:STIM2 DIG5
Set digital I/O lines 3 and 5 as trigger in lines. Generate a
trigger blender 1 event when a digital I/O trigger happens on
line 3 or 5.
Also see
:TRIGger:BLENder<n>:STIMulus<m> (on page 12-145)
:TRIGger:BLENder<n>:OVERrun?
This command indicates whether or not an event was ignored because of the event detector state.
Type Affected by Where saved Default value
Query only
Not applicable
Not applicable
Not applicable
Usage
:TRIGger:BLENder<n>:OVERrun?
<n>
The blender number (up to two)
Details
Indicates if an event was ignored because the event detector was already in the detected state when
the event occurred. This is an indication of the state of the event detector that is built into the event
blender itself.
