High Voltage SourceMeter Instrument Reference Manual Section 12:
SCPI command reference
2470-901-01 Rev. A / May 2019 12-83
Example
:SOURce:VOLTage:RANGe 3
Send this command to source levels around
3 V. This example selects the 20 V range for
the voltage source.
Also see
:SOURce[1]:<function>:RANGe:AUTO (on page 12-83)
Ranges (on page 4-37)
:SOURce[1]:<function>:RANGe:AUTO
This command determines if the range is selected manually or automatically for the selected source function.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Source configuration list
Save settings
Source configuration list
1 (ON)
Usage
:SOURce[1]:CURRent:RANGe:AUTO <state>
:SOURce[1]:CURRent:RANGe:AUTO?
:SOURce[1]:VOLTage:RANGe:AUTO <state>
:SOURce[1]:VOLTage:RANGe:AUTO?
<state>
Disable automatic source range: 0 or OFF
Enable automatic source range: 1 or ON
Details
This command indicates the state of the range for the selected source. When automatic source range
is disabled, the source range is set manually.
When automatic source range is enabled, the instrument selects the range that is most appropriate
for the value that is being sourced. The output level controls the range. If you read the range after the
output level is set, the instrument returns the range that the instrument chose as appropriate for that
source level.
If the source range is set to a specific value from the front panel or a remote command, the setting for
automatic range is set to disabled.
Example
SOUR:CURR:RANG:AUTO ON
Enable the automatic source range.
Also see
:SOURce[1]:<function>:RANGe (on page 12-82)
