2470

High Voltage SourceMeter Instrument Reference Manual Section 12:

SCPI command reference

2470-901-01 Rev. A / May 2019 12-21

Details

This command sets the lower limit for the limit Y test for the selected measure function. When limit Y

testing is enabled, this causes a fail indication to occur when the measurement value is less than this

value.

If you send this command without the <function> parameter, it will set the limit for all measure

functions.

Default is 0.3 for limit 1 when the diode function is selected. The default for limit 2 for the diode

function is –1.

Example

:CALC2:VOLT:LIM1:CLE:AUTO OFF

:CALC2:VOLT:LIM1:AUD FAIL

:CALC2:VOLT:LIM1:LOW 0.25

:CALC2:VOLT:LIM1:UPP 2.5

:CALC2:VOLT:LIMIT1:STAT ON

:READ?

:CALC2:VOLT:LIMIT1:FAIL?

:CALC2:VOLT:LIM1:CLE

Set limit autoclear off.

Enable the beeper for limit 1 when a voltage measurement

exceeds the limit.

Set lower limit 1 for voltage to 0.25 V.

Set upper limit 1 for voltage to 2.5 V.

Enable limit 1 testing for voltage.

Make a reading; the limit is checked and results display on the

front panel.

Return the test results; example output if the test fails on the

low limit:

LOW

Clear the test results.

Also see

:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page 12-23)
