High Voltage SourceMeter Instrument Reference Manual Section 5: Source-
measure considerations
2470-901-01 Rev. A / May 2019 5-29
Setting
Default value on
reset
MENU > Measure > Calculations > Math
:CALCulate[1]:<function>:MATH:STATe (on page 12-15)
smu.measure.math.enable (on page 14-134)
Off
MENU > Measure > Calculations > Limit1 > Auto Clear
:CALCulate2:<function>:LIMit<Y>:CLEar:AUTO (on page
12-17)
smu.measure.limit[Y].autoclear (on page 14-129)
On
MENU > Measure > Calculations > Limit1 > Low Value
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] (on page
12-20)
smu.measure.limit[Y].low.value (on page 14-133)
–1
MENU > Measure > Calculations > Limit1 > High Value
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page
12-23)
smu.measure.limit[Y].high.value (on page 14-133)
1
MENU > Measure > Calculations > Limit1 > Audible
:CALCulate2:<function>:LIMit<Y>:AUDible (on page 12-16)
smu.measure.limit[Y].audible (on page 14-128)
None
MENU > Measure > Calculations > Limit2 > Auto Clear
:CALCulate2:<function>:LIMit<Y>:CLEar:AUTO (on page
12-17)
smu.measure.limit[Y].autoclear (on page 14-129)
On
MENU > Measure > Calculations > Limit2 > Low Value
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] (on page
12-20)
smu.measure.limit[Y].low.value (on page 14-133)
–1
MENU > Measure > Calculations > Limit2 > High Value
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page
12-23)
smu.measure.limit[Y].high.value (on page 14-133)
1
MENU > Measure > Calculations > Limit2 > Audible
:CALCulate2:<function>:LIMit<Y>:AUDible (on page 12-16)
smu.measure.limit[Y].audible (on page 14-128)
None
Digital I/O reset values
Setting
Default value on
reset
Not available from front panel
:DIGital:LINE<n>:MODE (on page 12-24)
digio.line[N].mode (on page 14-52)
Digital line, input
Display reset values
Setting
Default value on
reset
SETTINGS swipe screen > Display Digits
:DISPlay:<function>:DIGits (on page 12-29)
smu.measure.displaydigits (on page 14-123)
5½
