4: Sourcing and measuring 2470 High Voltage SourceMeter Instrument
4-48 2470-901-01 Rev. A / May 2019
Setting a relative offset value
You can set a specific relative offset value using the front panel or remote commands.
Using the front panel:
1. Press the FUNCTION key and select the measure function.
2. Press the MENU key.
3. Select Calculations.
4. For Rel, select On.
5. Select Rel Value.
6. Enter the value and select OK.
Over a remote interface:
• SCPI commands: Refer to [:SENSe[1]]:<function>:RELative (on page 12-55) and
[:SENSe[1]]:<function>:RELative:STATe (on page 12-57).
• TSP commands: Refer to smu.measure.rel.level (on page 14-146) and smu.measure.rel.enable
(on page 14-145).
Using SCPI commands:
Send the commands:
:SENSe:FUNCtion "VOLTage"
:SENSe:VOLTage:RELative <n>
:SENSe:VOLTage:RELative:STATe ON
Where <n> is the amount of the offset.
To set the relative offset for another function, replace VOLTage with CURRent or RESistance.
Using TSP commands:
Send the commands:
smu.measure.func = smu.FUNC_DC_VOLTAGE
smu.measure.rel.level = relValue
smu.measure.rel.enable = smu.ON
Where relValue is the relative offset value.
To set the relative offset for another function, replace smu.FUNC_DC_VOLTAGE with
smu.FUNC_DC_CURRENT or smu.FUNC_RESISTANCE.
