4: Sourcing and measuring 2470 High Voltage SourceMeter Instrument
4-80 2470-901-01 Rev. A / May 2019
TRIG:BLOC:BRAN:LIM:CONS 10, IN, 106, 108, 23, 5
TRIG:BLOC:DIG:IO 11, 15, 15
TRIG:BLOC:DEL:CONS 12, 0.001
TRIG:BLOC:DIG:IO 13, 0, 15
TRIG:BLOC:NOT 14, 1
TRIG:BLOC:BRAN:COUN 15, 10, 2
TRIG:BLOC:BRAN:ALW 16, 0
TRIG:BLOC:DIG:IO 17, 1, 15
TRIG:BLOC:BRAN:ALW 18, 12
TRIG:BLOC:DIG:IO 19, 2, 15
TRIG:BLOC:BRAN:ALW 20, 12
TRIG:BLOC:DIG:IO 21, 3, 15
TRIG:BLOC:BRAN:ALW 22, 12
TRIG:BLOC:DIG:IO 23, 4, 15
TRIG:BLOC:BRAN:ALW 24, 12
 Block 10: Check if 106 ≤ R ≤ 108; if
yes, go to Block 23.
 Block 11: Set digital I/O lines 1
through 4; output decimal 15 (binary
1111) to component handler.
 Block 12: Delay 1 ms. Controls
duration of digital bit patterns;
adjust as appropriate.
 Block 13: Set digital I/O lines 1
through 4; output decimal 0 (binary
0000) clear pattern to component
handler.
 Block 14: Notify block generates
event, which causes output of a
trigger pulse on digital I/O line 6.
 Block 15: Loop back to Block 2;
keep looping until all resistors have
been tested.
 Block 16: Go to Block 0 (go to Idle).
 Block 17: Set digital I/O lines 1
through 4; output decimal 1 (binary
0001) to component handler.
 Block 18: Go to Block 12.
 Block 19: Set digital I/O lines 1
through 4; output decimal 2 (binary
0010) to component handler.
 Block 20: Go to Block 12.
 Block 21: Set digital I/O lines 1
through 4; output decimal 3 (binary
0011) to component handler.
 Block 22: Go to Block 12.
 Block 23: Set digital I/O lines 1
through 4; output decimal 4 (binary
0100) to component handler.
 Block 24: Go to Block 12.
