Tektronix Keithley SourceMeter 2470 Reference Manual

Section
5: Source-measure considerations 2470 High Voltage SourceMeter Instrument
Reference Manual
5-10 2470-901-01 Rev. A / May 2019
To set the number of PLCs for resistance measurements, send the command:
:SENSe:RESistance:NPLCycles <n>
To set NPLCs for voltage measurements, send the command:
:SENSe:VOLTage:NPLCycles <n>
Where <n> is a value from 0.01 to 10, with 0.01 resulting in the fastest reading rates and 10 resulting
i
n the lowest reading noise.
For example, to set NPLC for resistance measurements to 0.5, send the command
RES:NPLC 0.5
Using TSP commands:
To set NPLC, send the command smu.measure.nplc. For example, to set the NPLC value to 0.
5
f
or voltage measurements, send the commands:
smu.measure.func = smu.FUNC_DC_VOLTAGE
smu.measure.nplc = 0.5
To assign a different measure function, replace smu.FUNC_DC_VOLTAGE with one of the following:
• For current measurements: smu.FUNC_DC_CURRENT
• For resistance measurements: smu.FUNC_RESISTANCE

Tektronix Keithley SourceMeter 2470 Specifications

General

Model	2470
Type	SourceMeter
Category	Measuring Instruments
Channels	1
Voltage Source Range	±1000 V
Current Source Range	±1 A
Power	100 W
Current Measurement Resolution	10 pA
Measurement Resolution	6½ digits
Display	5 inch capacitive touchscreen
Interface	USB, GPIB, Ethernet
Supported Communication Protocols	SCPI
Input/Output Connectors	4-wire
