High Voltage SourceMeter Instrument Reference Manual Section 6:
2470-901-01 Rev. A / May 2019 6-15
Using the front panel:
1. Press the MENU key.
2. Under Measure, select Reading Buffers. The MANAGE READING BUFFERS window is
displayed.
Figure 115: MANAGE READING BUFFERS screen
3. Select a reading buffer from the list. For example, select testData.
Figure 116: Settings for reading buffer screen
4. Select the Make Active button. The "Are you sure" dialog box is displayed.
5. Select Yes.
You can also select reading buffers from the active buffer indicator on the home screen. Refer to
Active buffer indicator for information about using the indicator to select buffers.
