Section

8: Triggering 2470 High Voltage SourceMeter Instrument

Reference Manual

8-14 2470-901-01 Rev. A / May 2019

Figure 127: Digital I/O port configuration

For additional details about the digital output, see the 2470 specifications (available at the Keithley

Instruments support website (tek.com/support)).
