8: Triggering 2470 High Voltage SourceMeter Instrument
8-34 2470-901-01 Rev. A / May 2019
Reset Branch Count
This block creates a block in the trigger model that resets a branch counter to 0.
When you select the Reset Branch Count block, the following option is available.
Setting Description
Counter Block
Enter a number from 1 to 63.
Configuration list blocks
You can use configuration list blocks to recall settings that are stored in a configuration list. When the
trigger model reaches a configuration list block, the commands in the configuration list are executed.
The trigger model blocks that recall configuration lists are:
• Configuration recall
• Configuration next
• Configuration previous
For detail on configuration lists, see Configuration lists (on page 4-83
).
Config list recall block
When the trigger model reaches a configuration recall block, the settings in the specified configuration
list are recalled if a single configuration list is specified. If both measure and source configuration lists
are specified, measure and source settings are recalled from the next index in each list when this
block is reached. The index numbers recalled may not match; it depends on the number of indexes in
each list and what index number each list is on.
You can restore a specific set of configuration settings in the configuration list by defining the index.
The configuration lists must be defined before you can use this block. If one of the indices for the
configuration list changes, verify that the trigger model count is still accurate.
When you select the config list recall block, the following options are available.
Setting Description
Config List
The name of the configuration list to recall the index from.
Recall Index
Config List 2
The name of the second configuration list to recall the index from;
must be the opposite type of list than the first; for example, if the
first configuration list is a measure list, the second configuration list
Recall Index 2
The index to recall from the second configuration list.
