8: Triggering 2470 High Voltage SourceMeter Instrument
8-56 2470-901-01 Rev. A / May 2019
Respond to an event with a wait block
The wait building block causes the trigger model to stop and wait for an event or set of events to
occur before continuing. You can specify up to three events for each wait block. The wait block can
use any of the system trigger events. See Trigger events (on page 8-53
).
To continue the trigger model, it must receive the trigger event that is defined for the wait block.
Using the branch-on-event trigger blocks
The branch-on-event block goes to a branching block after a specified trigger event occurs. If the
trigger event has not yet occurred when the trigger model reaches the branch-on-event block, the
trigger model continues to execute the blocks in the normal sequence. After the trigger event occurs,
the next time the trigger model reaches the branch-on-event block, it goes to the branching block.
If you set the branch event to none, an error is generated when you run the trigger model.
The branch-on-event block can use any of the system trigger events. See Trigger events
(on page
8-53).
