High Voltage SourceMeter Instrument Reference Manual Section 9: TSP-Link and TSP-
Net
2470-901-01 Rev. A / May 2019 9-11
Use the commands in the following table to perform basic steady-state digital I/O operations; for
example, you can program the 2470 to read and write to a specific TSP-Link synchronization line or to
the entire port.
TSP-Link commands
Command Description
trigger.tsplinkin[N].clear() (on page 14-261)
Clears the event detector for a trigger
trigger.tsplinkin[N].edge (on page 14-262)
Indicates which trigger edge controls the trigger
event detector for a trigger line
trigger.tsplinkin[N].overrun (on page 14-263)
Indicates if the event detector ignored an event
while in the detected state
trigger.tsplinkin[N].wait() (on page 14-264)
Waits for a trigger
trigger.tsplinkout[N].assert() (on page 14-264)
Simulates the occurrence of the trigger and
generates the corresponding trigger event
trigger.tsplinkout[N].logic (on page 14-265)
Defines the trigger output with output logic for a
trigger line
trigger.tsplinkout[N].pulsewidth (on page
14-266)
Sets the length of time that the trigger line is
asserted for output triggers
trigger.tsplinkout[N].release() (on page
14-266)
Releases a latched trigger on the given TSP-Link
trigger line
trigger.tsplinkout[N].stimulus (on page
14-267)
Specifies the event that causes the
synchronization line to assert a trigger
tsplink.group (on page 14-269)
The group number of the TSP-Link node
tsplink.initialize() (on page 14-270)
Initializes all instruments and enclosures in the
TSP-Link system
tsplink.line[N].mode (on page 14-271)
Defines the trigger operation of a TSP-Link line
as digital in or out or trigger in or out
tsplink.line[N].reset() (on page 14-272)
Resets some of the TSP-Link trigger attributes to
their defaults
tsplink.line[N].state (on page 14-273)
Reads or writes the digital state of a TSP-Link
synchronization line
tsplink.master (on page 14-273)
Reads the node number assigned to the master
node
tsplink.node (on page 14-274)
Defines the node number
tsplink.readport() (on page 14-274)
Reads the TSP-Link synchronization lines as a
digital I/O port
tsplink.state (on page 14-275)
Describes the TSP-Link online state
tsplink.writeport() (on page 14-276)
Writes to all TSP-Link synchronization lines as a
digital I/O port
