Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-34 2470-901-01 Rev. A / May 2019
Details
The attribute is an array (a Lua table) of strings indicating the units of measure at the time of the
reading.
Example
reset()
testData = buffer.make(50)
smu.source.output = smu.ON
testData.fillmode = buffer.FILL_CONTINUOUS
trigger.model.load("SimpleLoop", 3, 0, testData)
smu.source.func = smu.FUNC_DC_CURRENT
trigger.model.initiate()
waitcomplete()
printbuffer(1, testData.n, testData.sourceunits)
trigger.model.load("SimpleLoop", 3, 0, testData)
smu.source.func = smu.FUNC_DC_VOLTAGE
trigger.model.initiate()
waitcomplete()
printbuffer(1, testData.n, testData.sourceunits)
smu.source.output = smu.OFF
Create a reading buffer named
testData, configure the instrument to
make three measurements, and store the
readings in the buffer.
Set the source output to ON.
Set the buffer to fill continuously.
Set the source function to current.
Take three readings.
Print the units for the first three readings
in the buffer.
Output:
Amp DC, Amp DC, Amp DC
Set the source function to voltage.
Take three readings.
Print the units for the readings in the
buffer.
Output:
Volt DC, Volt DC, Volt DC
Also see
bufferVar.sourceunits (on page 14-33)
bufferVar.sourcevalues (on page 14-35)
bufferVar.statuses (on page 14-37)
Reading buffers (on page 6-1)

Tektronix Keithley SourceMeter 2470 Specifications

General

Model	2470
Type	SourceMeter
Category	Measuring Instruments
Channels	1
Voltage Source Range	±1000 V
Current Source Range	±1 A
Power	100 W
Current Measurement Resolution	10 pA
Measurement Resolution	6½ digits
Display	5 inch capacitive touchscreen
Interface	USB, GPIB, Ethernet
Supported Communication Protocols	SCPI
Input/Output Connectors	4-wire
