Details
This function resets the following attributes to their default values:
 digio.line[N].mode
 trigger.digin[N].edge
 trigger.digout[N].logic
 trigger.digout[N].pulsewidth
 trigger.digout[N].stimulus
It also clears trigger.digin[N].overrun.
Example
-- Set the digital I/O trigger line 3 for a falling edge
digio.line[3].mode = digio.MODE_TRIGGER_OUT
trigger.digout[3].logic = trigger.LOGIC_NEGATIVE
-- Set the digital I/O trigger line 3 to have a pulsewidth of 50 microseconds.
trigger.digout[3].pulsewidth = 50e-6
-- Use digital I/O line 5 to trigger the event on line 3.
trigger.digout[3].stimulus = trigger.EVENT_DIGIO5
-- Print configuration (before reset).
print(digio.line[3].mode, trigger.digout[3].pulsewidth, trigger.digout[3].stimulus)
-- Reset the line back to factory default values.
digio.line[3].reset()
-- Print configuration (after reset).
print(digio.line[3].mode, trigger.digout[3].pulsewidth, trigger.digout[3].stimulus)
Output before reset:
digio.MODE_TRIGGER_OUT 5e-05 trigger.EVENT_DIGIO5
Output after reset:
digio.MODE_TRIGGER_IN 1e-05 trigger.EVENT_NONE
Also see
digio.line[N].mode (on page 14-52)
Digital I/O port configuration (on page 8-13)
trigger.digin[N].overrun (on page 14-200)
trigger.digout[N].pulsewidth (on page 14-203)
trigger.digout[N].stimulus (on page 14-204)
