Section

14: TSP command reference 2470 High Voltage SourceMeter Instrument

Reference Manual

14-62 2470-901-01 Rev. A / May 2019

Example

optionID = display.input.option("Select an option", "Apple", "Orange", "Papaya",

"Pineapple", "Blueberry", "Banana", "Grapes", "Peach", "Apricot", "Guava")

print(optionID)

This example displays the following dialog box:

If the user selects

Peach

, the return is

display.BUTTON_OPTION8

Also see

display.input.number() (on page 14-59)

display.input.prompt() (on page 14-63)

display.input.string() (on page 14-64)
