Tektronix Keithley SourceMeter 2470 Reference Manual

Section
14: TSP command reference 2470 High Voltage SourceMeter Instrument
Reference Manual
14-226 2470-901-01 Rev. A / May 2019
trigger.model.load("SortBinning", components, startInLine, startDelay, endDelay,
limit1High, limit1Low, limit1Pattern, allPattern, limit2High, limit2Low,
limit2Pattern, limit3High, limit3Low, limit3Pattern, limit4High, limit4Low)
trigger.model.load("SortBinning", components, startInLine, startDelay, endDelay,
limit1High, limit1Low, limit1Pattern, allPattern, limit2High, limit2Low,
limit2Pattern, limit3High, limit3Low, limit3Pattern, limit4High, limit4Low,
limit4Pattern)
trigger.model.load("SortBinning", components, startInLine, startDelay, endDelay,
limit1High, limit1Low, limit1Pattern, allPattern, limit2High, limit2Low,
limit2Pattern, limit3High, limit3Low, limit3Pattern, limit4High, limit4Low,
limit4Pattern, bufferName)
components
The number of components to measure (1 to 268,435,455)
limitxHigh
x is limit 1, 2, 3, or 4; the upper limit that the measurement is compared against
limitxLow
x
is 1, 2, 3, or 4; the lower limit that the measurement is compared against
limit1Pattern
The bit pattern that is sent when the measurement passes limit 1; range 1 to 15;
default is 1
limit2Pattern
The bit pattern that is sent when the measurement passes limit 2; range 1 to 15;
default is 2
limit3Pattern
The bit pattern that is sent when the measurement passes limit 3; range 1 to 15;
default is 4
limit4Pattern
The bit pattern that is sent when the measurement passes limit 4; range 1 to 15;
default is 8
allPattern
The bit pattern that is sent when all limits have failed; 1 to 15; default is 15
startInLine
The input line that starts the test; 5 for digital line 5, 6 for digital line 6; default is 5
startDelay
The delay time before each measurement (167 ns to 10 ks); default is
0
for no delay
endDelay
The delay time after the measurement (167 ns to 10 ks); default is 0 for no delay
bufferName
The name of the reading buffer, which may be a default buffer (defbuffer1 or
defbuffer2
) or a user-defined buffer; defaults to
defbuffer1
Details
This trigger model template allows you to sort components and place them into up to four bins, based
on the comparison to limits.
To set a limit as unused, set the high value for the limit to be less than the low limit.
All limit patterns and the all fail pattern are sent on digital I/O lines 1 to 4, where 1 is the least
significant bit.
After selecting a trigger model template, you can view the trigger model blocks in a graphical format
by pressing the front-panel MENU key and under Trigger, selecting Configure. You can also add or
delete blocks and change trigger model settings from this screen. You can use the
trigger.model.getblocklist() command to view the trigger model blocks in a list format.
Also see
None
