Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 2-51
Theory of Operation
Black and White Mode
s6500-062
Gear D1
Gear D2
Gear DK
Gear D1 Gear P2
Main DriveSub Motor
Gear D5
Magnet Gear (K)
Gear D3 In
Sub Drive
Gear D3 Out
Flange D3
Cam C
Gear C
Gear P4-2
Gear P4
Gear P3
Color Mode
Switching
Solenoid
Feed Drive
Hsg Assy Deve (K)
[ Magnet Roller (K) ]
Imaging Unit
s6500-063
Gear DK
Gear D1
Sub Motor
Gear D1
Gear D2
Gear D5
Magnet Gear (K)
[ Magnet Roll (K) ]
Sub Drive
Feed Drive
Developer (K)
Gear D3 In
Gear D3 Out
Gear P2
Gear P3
Color Mode
Switching Solenoid
Gear P4
Gear C
Cam C
Flange D3
Gear P4-2
Imaging Unit
Main Drive
: Indicates The Engagement Of Gears.
Cam C
Flange D3
Gear D2
Gear D4
Gear D3 In
Gear D3 Out

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
