Xerox WorkCentre 6505 Service Manual

2-52 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Theory of Operation
Color Mode
s6500-064
Gear D1
Gear D2
Gear DK
Gear D1
Sub Motor
Gear D5
Magnet Gear (K)
Sub Drive Feed Drive
Gear D3 In
Gear D3 Out
Developer
Housing (K)
[ Magnet Roll (K) ]
Magnet Gear (C)
[ Magnet Roll (C) ]
Magnet Gear (M)
Developer
Housing (M)
[ Magnet Roll (M) ]
Magnet Gear (Y)
Gear D5 Gear D5 Gear D5
Gear D4
Gear D4
Developer
Housing (Y)
[ Magnet Roll (Y) ]
Imaging Unit
Developer
Housing (C)
s6500-065
Gear DK
Gear D1
Sub Motor
Gear D1
Gear D2
Gear D5
Magnet Gear (K)
[ Magnet Roller (K) ]
Sub Drive
Feed Drive
Developer (K)
Gear D4
Magnet Gear (C)
[ Magnet Roller (C) ]
Developer (C)
Magnet Gear (M)
[ Magnet Roller (M) ]
Magnet Gear (Y)
[ Magnet Roller (Y) ]
Developer (Y)
Developer (M)
Gear D5
Gear D5
Gear D4
Gear D5
Imaging Unit
Gear D2
Gear D4
Gear D3 In
Gear D3 Out
: Indicates The Engagement Of Gears
Front
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
