Xerox WorkCentre 6505 Service Manual

4-78 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
General Troubleshooting
22 Reseat the Sub-Drive Assembly.
Test the Sub Drive (page 4-30):
Service Mode > Engine Diag > Motor
Test > Sub Motor FULL2.
Is the noise still present?
Replace in
order:
Imaging Unit
(page 8-7)
Fuser
(page 8-10)
Sub Drive
Assembly
(page 8-113)
.
Complete
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
