Reference
ESD Electrostatic Discharge. A transfer of charge between bodies at
different electrostactic potential.
ESS Image process controller
FCC Federal Communications Commission
FDR Feeder
FPOT First Print Output Time
FRU Field Replaceable Unit
GB Giga Byte
GDI Graphics Device Interface
GND Ground
HARN Harness
HCF High-Capacity Feeder
HDD Hard Disk Drive
HUM Humidity
HV High Voltage
HVPS High-Voltage Power Supply
Hz Hertz (cycles per second)
IDT Intermediate Drum Transfer
IEC International Electrotechnical Commission
I/F Interface
IIT Image Input Terminal - ADF, Scanner
IOT Image Output Terminal - the printer
IP Image Processor
KB Kilo Byte
LAN Local Area Network
LCD Liquid Crystal Display
LD Laser Diode
LED Light Emitting Diode
LEF Long-Edge Feed
LPD Line Printer Daemon
LPR Line Printer Remote
LTR Letter Size Paper (8.5 x 11 inches)
LVPS Low-Voltage Power Supply
MB Mega Byte
MCU Machine Control Unit (Engine Control Board)
MHz Mega Hertz
MIB Management Information Base
Acronym Description

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
