Xerox WorkCentre 6505 Service Manual

A-20 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Reference
MM Millimeters
MOT Motor
MPT Multi-Purpose Tray
NCS Non-Contact Sensor
NVM Non-Volatile Memory
NVRAM Non-Volatile Random Access Memory
OHP Overhead Paper (Transparency)
OPT Optional
OS Operating System
PCB Printed Circuit Board
PCL Printer Command Language
PDL Page Description Language
P/J Plug Jack (electrical connections)
PJL Printer Job Language
PL Parts List
POP3 Post Office Protocol version 3
PPD PostScript Printer Description
PPM Pages Per Minute
PWBA Printed Wiring Board Assembly
RAM Random Access Memory
RH Relative Humidity
RMS Root Mean Square Voltage
ROM Read-Only Memory
ROS Raster Output Scanner - Laser Unit
SEF Short-Edge Feed
SMB Server Message Block
SNMP Simple Network Management Protocol
SNR Sensor
SOL Solenoid
SOS Start of Scan
SSF (or SSI) Single-Sheet Feed or Input. SSF is used in error messages and
SSI is used in parts references to indicate the Manual Feed slot.
TDC Toner Density Control
TNR Toner
UI User Interface
USB Universal Serial Bus
WINS Wireless Integrated Network Sensor
Acronym Description
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
